Model:XQRY-120

Model:XQRY-160

電加熱功率electric heating power

10KW

12KW

工作溫度范圍working temperature range

160～180℃

160～180℃

最高溫度Max.temperature

240℃

240℃

儀表控制溫度精度誤差instrument control temperature accuracy error

±2℃

±2℃

工件溫度誤差workpiece temperature error(within 1 meter)

±10℃

±10℃

液壓系統工作壓力范圍hydraulic system working pressure range

3～6Mpa

3～6Mpa

液壓壓頭數量hydraulic press head qty.

6

8

液壓壓頭壓力范圍hydraulic press head pressure range

1000-2000 kgf

1000-2000 kgf

線圈單邊壓緊力范圍coil single edge pressing force range (three press heads resultant force)

3000-6000kgf

4000-8000kgf

線圈開檔W范圍coil open mouth W field

190～650mm

200～1000mm

線圈直線邊L3長度范圍coil straight edge length L3 range

≤1200mm

≤1600mm

線圈最大截面coil max.section

32×65mm2

32×65mm2

模具總長mould total length

1650mm

2000mm

發熱管長度heating tube length

1450mm

1850mm

有效發熱區長度effective heating area length

1200mm

1700mm
